Soundscape Product Listing

TRUAUDIO

SUBWOOFERS

A huge part of the Home Theater Experience is feeling the low rubble as the helicopter passes over head or having the whole room shake when a car blows up. Our line of subwoofers are perfect to add the needed low bass that today’s movies demand. Depending on the size of your room and how much “boom” you want, we have different models to choose from.

IN-WALL SUBWOOFERS

SUB-88a

Soundscape Price:$600 each

This is one of the best in-wall subwoofer available today! Surpassed only by the finest stand alone subwoofers on the market today. If true infrasonic bass is what your looking for then look no further than the SUB-88a!

• Dual 8", passive in-wall subwoofer
• Top of the line aluminum woofers for deep, powerful bass
• Frame and grill can be painted to blend in
• Front mounted controls for easy adjustments
• Great for Audio or video
• Mounts in standard 2 x 4 wall depth
• Recommenced use of MDF in-wall enclosure, TA # EL-SUB88
• Speaker Type: In-wall passive
• Subwoofer Enclosure design: Front Firing Slot-loaded
• Drivers: Dual 8" aluminum
• Power: 5 - 200 watt
• Impedance: 8 ohm
• Frequency Response: 37 - 180 Hz
• Sensitivity: 90 dB
• Crossover: 50 Hz, 100 Hz, 150 Hz, bypass In-wall enclosure: Must use MDF in-wall enclosure (model # EL-SUB88A)
• Finish dimensions: 22 3/4” H, 12 3/4” W, 3 3/4” D
• Cutout dimensions: 21 3/4" H, 11 1/2" W

---

FREESTANDING SUBWOOFERS

Cs-12

Soundscape Price:$650 each

12", 200 watt Powered subwoofer Front mounted slot port allows for cabinetry or flush wall mounting Proprietary cellulose composite woofer material Specailly designed internal amplifier for high power but low heat Mulitple input options to fit any system Small, good looking cabinet Available in white or black, lightly textured

• Speaker Type: Powered Subwoofer
• Enclosure design: Front Firing Slot-loaded
• Driver: 12"
• Power: 200 watt RMS internal amplifier
• Frequency Response: 30 - 180 Hz (-+3dB)
• Sensitivity: 113 db SPL @ 1meter
• Crossover: 50-180 Hz continuously variable low pass
• Input 1: Stereo RCA line level Input 2: LFE RCA Input 3: Speaker-level w/ banana posts
• Finish dimensions: 16” H, 14 Ό” W, 15 Ύ” D
• Available Colors Black, light textured

Cs-10

Soundscape Price:$450 each

10", 150 watt Powered subwoofer Front mounted slot port allows for cabinetry or flush wall mounting Proprietary cellulose composite woofer material Specailly designed internal amplifier for high power but low heat Mulitple input options to fit any system Small, good looking cabinet Available in white or black, lightly textured

• Speaker Type: Powered Subwoofer
• Enclosure design: Front Firing Slot-loaded
• Driver: 10"
• Power: 150 watt RMS internal amplifier
• Frequency Response: 32 - 150 Hz (-+3dB)
• Sensitivity: 110 db SPL @ 1meter
• Crossover: 50-180 Hz continuously variable low pass
• Input 1: Stereo RCA line level Input 2: LFE RCA Input 3: Speaker-level w/ banana posts
• Finish dimensions: 14” H, 13” W, 14 Ό” D
• Available Colors Black, light textured

Cs-8

Soundscape Price:$325 each- Black
Soundscape Price:$350 each - White

8", 100 watt Powered subwoofer Front mounted slot port allows for cabinetry or flush wall mounting Proprietary cellulose composite woofer material Specailly designed internal amplifier for high power but low heat Mulitple input options to fit any system Small, good looking cabinet Available in white or black, lightly textured

• Speaker Type: Powered Subwoofer
• Enclosure design: Front Firing Slot-loaded Driver: 8" cellulose composite
• Power: 100 watt RMS internal amplifier
• Frequency Response: 35 - 180 Hz (-+3dB)
• Sensitivity: 108 db SPL @ 1meter
• Crossover: 60-180 Hz continuously variable low pass
• Input 1: Stereo RCA line level Input 2: LFE RCA Input 3: Speaker-level w/ banana posts
• Finish dimensions: 13” H, 12” W, 13 ½” D
• Available Colors Black or White, light textured

Speaker Accessories

All Rough-in Rings are $15.00 each

Back Boxes for 6 /12" or 8" Ceiling Speakers are $22.00 each

MDF Enclosures for In-wall speakers are $60.00 each

MDF Enclosures for SUB-88 are $80.00 each

Acoustic Foam for in-wall speakers are $60/pair
